| Manufacturer | PCE | |
| Type of connector | AC supply | |
| Connector | socket | |
| Kind of connector | female | |
| Current rating | 32A | |
| Standard | IEC 60309 | |
| IP rating | IP44, IP54 | |
| Type of pin configuration | 2P+PE | |
| Number of pins | 3 | |
| Polarisation | 6H | |
| Mechanical mounting | for panel mounting | |
| Wire cross-section | 2.5…6mm2 | |
| Contact material | brass | |
| Electrical mounting | screw terminal | |
| Spatial orientation | angled | |
| Rated voltage | 230V AC |
